SIMATIC WinCC Unified V19 is the new visualisation system in the TIA Portal.
From operation directly at the machine to the integration of IT systems into the automation, WinCC Unified is fit and ready to meet not only current requirements but also those of the future.
The system is impressive in its use of native web technologies (HTML5, SVG and JavaScript) as well as a high degree of openness thanks to powerful interfaces for data exchange.
The key advantages at a glance
Technology
WinCC Unified has been completely redesigned and is using native web technologies such as HTML5, SVG and JavaScript. This enables access to visualization from any modern web browser, without the need to install additional plug-ins. The enginering tool is the TIA Portal.
Scalability
WinCC Unified offers a fully scalable scope of functions, from the machine-level application up to a large distributed SCADA system. HMI Projekte or parts of the project can be re-used from a machine near level to a SCADA application..
Everywhere
Due to the modern architecture, it will be possible to execute functionalities of WinCC Unified in different environments. In addition to the classic “OnPremise” applications, WinCC Unified can also be executed in the edge or cloud environment in the future. With the first version, WinCC Unified is available for panel and PC-based solutions. The use in the edge and cloud environment will be possible with a following delivery stage.
Openness (integration platform)
On the basis of the modern architecture it will be possible to execute functionalities of WinCC Unified in various environments. Apart from the classic “on-premise” application cases, in future WinCC Unified will also be executable in the Edge or Cloud environment.
In its initial version, WinCC Unified is available for panel- and PC-based solutions. Its use in the Edge and Cloud environment will be possible with a subsequent delivery stage.
For additional information please go to: The future of visualization starts now!
SIMATIC WinCC Unified ES V19 - Information for the Engineering Software
Notes on licensing the engineering software
Every customer who buys a license for WinCC Comfort V19, WinCC Advanced V19 or WinCC Professional V19 or receives it as part of the Software Update Service (SUS) can use the corresponding WinCC Unified version free of charge.
Licence compatibilty
A WinCC Unified ES can be installed by parallel with a WinCC Advanced ES on one computer. Valid licenses for a WinCC Unified ES can also be used for engineering a WinCC Advanced (and vice versa).
A WinCC Unified ES cannot be installed parallel to a WinCC Professional ES on a computer. Valid licenses for a WinCC Unified ES can also be used for engineering a WinCC Professional (and vice versa). To do this, the licenses must be transferred to the WinCC Professional ES computer.
Operating Systems
Configuration | Remark | |
|---|---|---|
Windows 10 Pro | Windows 10 Pro Version 1809 Windows 10 Pro Version 1903 | |
Windows 10 Enterprise
| Windows 10 Enterprise Version 1809 Windows 10 Enterprise Version 1903 | 64-bit |
Windows 10 IoT Enterprise
LTSB (Test for IPC) | Windows 10 IoT Enterprise 2015 LTSB Windows 10 IoT Enterprise 2016 LTSB Windows 10 IoT Enterprise 2019 LTSC | |
Windows Server 2012 R2 StdE Windows Server 2016 Standard Windows Server 2019 Standard | Full Installation | 64-Bit |
SIMATIC WinCC Unified ES V19 - Information for the Runtime Software
Important information
Base functionality
File-based Logging | Local data acquisition for small to medium applications |
|---|---|
Parameter Control
| Uniform management and control of machine or production parameters
|
Collaboration
| Structure of decentralised configurations
|
Clients | Flexible web-based remote control
|
Available options
Base options (chargeable)
File-based Logging | Local data acquisition for small to medium applications |
|---|---|
Parameter Control
| Uniform management and control of machine or production parameters
|
Collaboration
| Structure of decentralised configurations
|
Clients | Flexible web-based remote control
|
SCADA options
ddddddd | |
|---|---|
Database option
| Extensive, high-performance long-term archiving
|
Frequently Asked Questions (FAQs)
- User Login on operator panels with RFID CardReader
- Migration of plants with SIMATIC (TIA Portal) - Controllers
- TIA Portal - An Overview of the Most Important Documents and Links - Communication
- SIMATIC WinCC in Online Support
- SIMATIC WinCC Unified Tutorial Center
- Most Important Documents and Links - Visualisation
