SIMATIC Industrial Tablet PC
SIMATIC ITP1000: Industrial rugged PC
- High-quality components and modules with a high MTBF (mean time between failure), which also ensure 24-hour operation in the extended temperature range up to +45 °C
- Rugged enclosure designs with high electromagnetic compatibility (EMC)
- Hardware available in the long term
Powerful and many functions on board
- High-performance Intel Core i5-6442EQ or Intel Celeron G3902E notebook CPU
- Many interfaces on board: LAN, SD card reader, USB interfaces, RS232, audio
- WLAN and Bluetooth integrated
- RFID, bar code reader (1D/2D) and camera for a highly diverse range of mobile applications
- Windows 7 Ultimate 64-bit / Windows 10 IoT Enterprise 2016 LTSB (64-bit)
SIMATIC IPC277E - Embedded IPC
Based on the IPC227E Box PC, the SIMATIC IPC277E Panel PC provides the highest industry functionality for flexible deployment in harsh conditions – and all this maintenance-free.
The Nanopanel PC SIMATIC IPC277E is a flexible embedded industrial PC with rugged and durable displays. It is based on the Box PC IPC227E technologically and provides the highest industry functionality for flexible deployment in harsh conditions – and all this maintenance-free.
SIMATIC IPC377E - Basic IPC
The SIMATIC IPC 377E Panel PC: an immediately available, economical package comprising a SIMATIC Industrial PC and operator display for industrial applications.
The SIMATIC IPC377E Panel PC provides a preconfigured, turnkey and complete solution comprising a SIMATIC Industrial PC and a brilliant, rugged single-touch display with glass front available with 12, 15 or 19 inch diagonal screen. The Panel PC is especially well suited for all industrial applications, especially for economical implementation of HMI applications, the acquisition and networking of production and energy data in production environments, such as assembly workstations, warehouses and logistics systems, or for standard applications in the image processing field. It is easy to integrate also in existing machines and plant concepts. The SIMATIC IPC377E is available directly from stock in a total of six variants (12″/15″/19″, each without operating system or with preinstalled Windows 7 Ultimate / Windows 10 Enterprise LTSB 2016) and at an attractive package with corresponding HMI software.
SIMATIC IPC477E - Embedded IPC
The SIMATIC IPC477E is a fan-free embedded panel PC with powerful 6th generation Intel Core-i processor for complex visualization and control tasks.
The SIMATIC IPC477E is a fan-free embedded panel PC for complex visualization and control tasks with single- and multi-touch display.
It is maintenance-free and can be configured, integrated, and commissioned flexibly and simply. With its rugged metal enclosure, it can withstand even severe mechanical stress.
Benefits
High degree of industrial capability
The entire construction is designed for industrial use, be it high temperature in continuous running duty or industrial EMC requirements.
Investment protection
High component continuity and guaranteed availability of spare parts for up to 5 years after product phase-out are ensured, e.g. through the development and production of our own motherboards. This enables long-lasting machine concepts without renewed engineering effort.
Easy integration
Thanks to the full-fledged Windows operating system, the SIMATIC ITP1000 is easy to integrate into the existing IT Infrastructure.
High performance
Thanks to the notebook CPU used, the SIMATIC ITP1000 is a fully fledged PC, which can be turned into an office workstation using a docking station. Mobile applications on tablet PCs give rise to new application possibilities.
Lightweight and compact
Despite high device performance and many integrated functions, the SIMATIC ITP1000 is highly compact and weighs in at only 1.6 kg
Options
A wide range of options (RFID, bar code reader, camera) provide a tailor-made solution for your industrial application.
Other advantages
- Low-cost SIMATIC runtime software packages are available when SIMATIC ITP1000 is ordered along with the software
- Comprehensive accessories for a variety of applications (e.g. docking station, bags)
- Customised design and functional adaptations possible
Application
Typical application areas are to be found in service/maintenance, within the scope of Industry 4.0 (“paperless factory”), for production planners, power data management or, for example, measuring and testing tasks.
Design
Design
The SIMATIC ITP1000 is a table PC with high computing capacity.
- Interfaces (under service flap)
- 1 x LAN 10/100/1 000 Mbps Ethernet interface (RJ45)
- 2 x USB V3.0·1 x RS232
- 1 x mini-display port (resolution: up to 4 096 x 2 304@60Hz)
- Other interfaces
- 1 x SD card reader
- 1 x Type C USB
- 1 x Universal Audio Jack (UAJ)
- 1 x DC-in
- Docking interface
Design versions
- Processor/main memory configuration:
- Intel Celeron G3902E (2M cache, 1.60 GHz)
- Intel Core i5 6442EQ, 1.9 GHz (2.7 GHz), Quad Core
- Main memory capacity:
- 4 GB, 8 GB or 16 GB DDR4-RAM
- Drives:
- Solid-state drive, 256 GB, M.2
- Solid-state drive, 512 GB, M.2
- Operating system preinstalled:
- Without operating system
- Windows 7 Ultimate 64-bit, multi-language
- Windows 10 IoT Enterprise 2016 LTSB (64-bit)
- Further options (possible in every combination)
- None
- Camera (5 megapixels with torch function)
- RFID reader (13.56 MHz)
- 1D/2D bar code reader
Components of the operator control unit
- 10″ multi-touch display
- 1 280 x 800 resolution
- 8 side function keys
Technical specifications
