3SE52120RV40

Safety position switch with separate actuator, metal enclosure, 31 mm

Manufacturer's No: 3SE5212-0RV40     Manufacturer: Siemens
Safety position switch with separate actuator, metal enclosure, 31 mm

View 3D

Availability Back Order

£45.57
  • Safety position switch with separate actuator
  • Metal enclosure with a diameter of 31 mm
  • Head made of plastic
  • Slow-action contacts: 1 NO + 1 NC
  • 5 directions of approach
  • Matching separate actuator model: 3SE5000-0AV0./-0AW.
  • Actuator must be ordered separately

Selectable mandatory product

Accessories



Product

Manufacturer Material ID -
3SE5212-0RV40
Net Weight -
0.23kg

Additional Product Information

Commodity Code -
85365080
Country of Origin -
DE
Export Control Regulations -
AL: N / ECCN: N
Minimum Order Quantity -
1
RoHs Compliance -
YES
UNSPSC -
39122216

Technical Specification

-
Siemens
Rated operation current Ie at AC-15, 230 V -
- Ampere
Rated operation current Ie at DC-13, 230 V -
- Ampere
Rated operation current Ie at AC-15, 125 V -
- Ampere
Degree of protection (NEMA) -
UN
Material housing -
Metal
Degree of protection (IP) -
IP66/IP67
Type of interface -
None
Housing material -
Metal
Suitable for safety functions -
Coating housing -
Lacquered
Type of switching contact -
Slow-action switch
Type of interface for safety communication -
None
Type of electric connection -
Cable entry metrical
Explosion safety category for gas -
None
Explosion safety category for dust -
None
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP66/IP67
Forced opening -
Number of safety auxiliary contacts -
1
Interface type -
None
Rated operation current Ie at AC-15, 24 V -
6 Ampere
Rated operation current Ie at DC-13, 125 V -
0.55 Ampere
Rated operation current Ie at DC-13, 24 V -
3 Ampere
Width sensor -
31 Millimetre
Height of sensor -
33 Millimetre
Length of sensor -
104 Millimetre
Ambient temperature during operating -
-25 Degrees celsius
Number of contacts as normally closed contact -
1
Number of contacts as normally open contact -
1
Number of contacts as change-over contact -
0

Availability Back Order

£45.57
