1SVR730760R0500

Current window monitor with tripping delay. 0.3 - 15A, 24-240 V AC/DC input voltage

Manufacturer's No: CM-SFS.22S     Manufacturer: ABB
Current window monitor with tripping delay. 0.3 - 15A, 24-240 V AC/DC input voltage

Availability Back Order

£236.05
  • Single-functional current monitoring relay CM-SFS.22S
  • Input voltage: 24-240 V AC/DC
  • Current measuring ranges: 0.3-1.5 A, 1-5 A, 3-15 A
  • Output: 2 c/o (SPDT) contacts rated at 250 V / 4 A
  • Features window monitoring for over- and undercurrent
  • Adjustable tripping delay: 0 to 30 seconds
  • Hysteresis fixed at 5% of threshold value
  • Options for ON- or OFF-delay, open- or closed-circuit operation
  • Configurable output contacts as 1x2 c/o (SPDT) or 2x1 c/o (SPDT)
  • Start-up delay range: instantaneous to 30 seconds

Read more

  • Sealable transparent cover for protection against unauthorized changes
  • Screw connection technology with double-chamber cage connection terminals


Product

Manufacturer Material ID -
CM-SFS.22S
Net Weight -
0.16kg

Additional Product Information

Commodity Code -
85364900
Country of Origin -
DE
Minimum Order Quantity -
1
UNSPSC -
39121529

Technical Specification

-
ABB
Rated control supply voltage Us at AC 50HZ -
24 Volt
Rated control supply voltage Us at AC 60HZ -
24 Volt
Rated control supply voltage Us at DC -
24 Volt
Width -
22.5 Millimetre
Height -
85.6 Millimetre
Depth -
103.7 Millimetre
Current measurement range -
0.3 Ampere
Single-phase hysteresis possible -
Single-phase under current possible -
Single-phase over current possible -
Contains function DC-voltage under current -
Contains function DC-voltage over current -
Function DC-current hysteresis -
Type of electric connection -
Screw connection
Rated control supply voltage at AC 50 Hz -
24 Volt
Rated control supply voltage at AC 60 Hz -
24 Volt
Rated control supply voltage at DC -
24 Volt
Max. permitted delay-on energization time -
30 Second
Min. adjustable delay-on energization time -
0.1 Second
Max. permitted off-delay time -
30 Second
Min. adjustable off-delay time -
0.1 Second
Voltage type for actuating -
AC/DC
Number of contacts as normally closed contact -
0
Number of contacts as normally open contact -
0
Number of contacts as change-over contact -
2
Current type -
AC/DC
External power supply required -
Operating voltage at AC 50 Hz -
230 Volt
Operating voltage at AC 60 Hz -
230 Volt
Rated switch current -
4 Ampere
Response value amperage 1 -
0.3 Ampere
Response value amperage 2 -
0.3 Ampere
Supply voltage AC 50 Hz -
24 Volt
Supply voltage AC 60 Hz -
24 Volt
Supply voltage DC -
24 Volt
Voltage type (operating voltage) -
AC
Voltage type of supply voltage -
AC/DC
ABB

Availability Back Order

£236.05
