1SVR730830R0400

Over or Under voltage monitor with tripping delay. 3-600V, 24-240 V AC/DC input voltage

Manufacturer's No: CM-ESS.2S     Manufacturer: ABB
Over or Under voltage monitor with tripping delay. 3-600V, 24-240 V AC/DC input voltage

Availability Back Order

£217.72
  • Voltage monitoring relay CM-ESS.2S
  • Input voltage range: 24-240 V AC/DC
  • Output: 2 c/o (SPDT) contacts rated at 250 V / 4 A
  • Measuring ranges: 3-30 V, 6-60 V, 30-300 V, 60-600 V
  • Operating principle: RMS measuring for DC and AC voltages
  • Configurable for over- or undervoltage monitoring
  • Adjustable hysteresis range: 3-30% of threshold value
  • Adjustable tripping delay range: instantaneous to 30 s (0, 0.1-30 s)
  • Transparent cover for protection against unauthorized changes
  • Screw connection technology with double-chamber cage connection terminals


Product

Manufacturer Material ID -
CM-ESS.2S
Net Weight -
0.14kg

Additional Product Information

Commodity Code -
85364900
Country of Origin -
DE
Minimum Order Quantity -
1
UNSPSC -
39121529

Technical Specification

-
ABB
Voltage measurement range 2 -
- Volt
Rated control supply voltage Us at AC 50HZ -
24 Volt
Rated control supply voltage Us at AC 60HZ -
24 Volt
Rated control supply voltage Us at DC -
24 Volt
Width -
22.5 Millimetre
Height -
85.6 Millimetre
Depth -
103.7 Millimetre
Single-phase under voltage possible -
Single-phase over voltage possible -
Single-phase hysteresis possible -
Contains function DC-under voltage -
Contains function DC-over voltage -
Contains function DC-voltage hysteresis -
Type of voltage measurement range -
AC/DC
Type of electric connection -
Screw connection
Rated control supply voltage at AC 50 Hz -
24 Volt
Rated control supply voltage at AC 60 Hz -
24 Volt
Rated control supply voltage at DC -
24 Volt
Voltage measurement range 1 -
3 Volt
Max. permitted delay-on energization time -
0 Second
Min. adjustable delay-on energization time -
0 Second
Max. permitted off-delay time -
30 Second
Min. adjustable off-delay time -
0.1 Second
Response value voltage -
3 Volt
Voltage type for actuating -
AC/DC
Number of contacts as normally closed contact -
0
Number of contacts as normally open contact -
0
Number of contacts as change-over contact -
2
ABB

Availability Back Order

£217.72
