6ES71366DC000CA0

SIMATIC DP, Electronics module ET 200SP, F-DQ 8XDC 24V0.5A PP, 15 mm width, up to PL E (ISO 13849) u

Manufacturer's No: 6ES7136-6DC00-0CA0     Manufacturer: Siemens
SIMATIC DP, Electronics module ET 200SP, F-DQ 8XDC 24V0.5A PP, 15 mm width, up to PL E (ISO 13849) u

View 3D

Availability In Stock

£299.00
  • SIMATIC DP electronic module ET 200SP
  • Model: F-DQ 8x24VDC/0.5A PP HF
  • Width: 15 mm
  • Safety level: PL E (ISO 13849), SIL 3 (IEC 61508)
  • Output: 8 channels, 24V DC, 0.5A each

Mandatory additional product

SIMATIC ET 200SP BU type A0 BU15-P16+A10+2B PU 10

Product Code - 6ES71936BP202BA0
Price £22.00
Back Order

SIMATIC ET 200SP BU type A0 BU15-P16+A10+2D PU 10

Product Code - 6ES71936BP202DA0
Price £34.00
Back Order

Spare part

Product video


Product

Manufacturer Material ID -
6ES7136-6DC00-0CA0
Net Weight -
0.06kg

Additional Product Information

Commodity Code -
85389091
Country of Origin -
DE
Export Control Regulations -
EAR99H / N
Minimum Order Quantity -
1
UNSPSC -
32151705

Technical Specification

Input current at signal 1 -
- Milliampere
Time delay at signal exchange -
- Millisecond
Type of voltage (input voltage) -
UN
Category according to EN 954-1 -
UN
Supply voltage AC 50 Hz -
- Volt
Supply voltage AC 60 Hz -
- Volt
Permitted voltage at input -
- Volt
Degree of protection (IP) -
IP20
Number of interfaces PROFINET -
0
Performance level acc. EN ISO 13849-1 -
Level e
STATFLAG -
A
Width -
15 Millimetre
Height -
73 Millimetre
Depth -
58 Millimetre
Suitable for safety functions -
Number of digital inputs -
0
Number of digital outputs -
8
Voltage type of supply voltage -
DC
Number of HW-interfaces industrial Ethernet -
0
Number of HW-interfaces RS-232 -
0
Number of HW-interfaces RS-422 -
0
Number of HW-interfaces RS-485 -
0
Number of HW-interfaces serial TTY -
0
Number of HW-interfaces USB -
0
Number of HW-interfaces parallel -
0
Number of HW-interfaces other -
0
Output current -
0.5 Ampere
Short-circuit protection, outputs available -
Type of digital output -
Other
Type of electric connection -
Plug-in connection
Rail mounting possible -
Explosion safety category for gas -
ATEX gas-ex-protection, Cat. 3G
Explosion safety category for dust -
None
Fieldbus connection over separate bus coupler possible -
System accessory -
Degree of protection (IP rating) -
IP20
Number of HW-interfaces PROFINET -
0
Number of HW-interfaces Wireless -
0
Performance level acc. to EN ISO 13849-1 -
Level e
Supporting protocol for PROFIsafe -
Supply voltage DC -
19.2 Volt
Permitted voltage at output -
19.2 Volt
Type of output voltage -
DC
Digital outputs configurable -
SIL according to IEC 61508 -
3

Availability In Stock

£299.00
