6ES73325HF000AB0

SM 332, 8 analogue outputs, 11/12 bit, 40 Pin Connector Required

Manufacturer's No: 6ES7332-5HF00-0AB0     Manufacturer: Siemens
SM 332, 8 analogue outputs, 11/12 bit, 40 Pin Connector Required

View 3D

Availability Back Order

£1,617.00
  • SIMATIC S7-300 Analog output module SM 332
  • Isolated with 8 analog outputs (AO) for voltage/current (U/I)
  • Diagnostics feature included
  • Resolution of 11/12 bits
  • 40-pole module
  • Hot swapping possible with active backplane bus

Accessories



Product

Manufacturer Material ID -
6ES7332-5HF00-0AB0
Net Weight -
0.33kg

Additional Product Information

Commodity Code -
85389091
Country of Origin -
DE
Export Control Regulations -
AL: N / ECCN: N
Minimum Order Quantity -
1
RoHs Compliance -
Yes
UNSPSC -
32151705

Technical Specification

-
Siemens
-
Siemens
Resolution of the analogue inputs -
- Bit
Category according to EN 954-1 -
UN
Performance level acc. EN ISO 13849-1 -
UN
SIL according to IEC 61508 -
UN
Type of electric connection -
Screw-/spring clamp connection
Explosion safety category for gas -
ATEX gas-ex-protection, Cat. 3G
Analogue outputs configurable -
Depth -
117 Millimetre
Explosion safety category for dust -
None
Height -
125 Millimetre
Number of analogue inputs -
0
Number of analogue outputs -
8
Output signal configurable -
Output, current -
Output, voltage -
Resolution of the analogue outputs -
12 Bit
Width -
40 Millimetre

Availability Back Order

£1,617.00
