6ES71384FR000AA0

ET200S 1 Relay Output Failsafe, 24 V DC/5A 24 - 230 V AC/5A

Manufacturer's No: 6ES7138-4FR00-0AA0     Manufacturer: Siemens
ET200S 1 Relay Output Failsafe, 24 V DC/5A 24 - 230 V AC/5A

View 3D

Availability Back Order

POA
  • Electronics module 1F-RO for ET200S
  • 1 relay output (2 NO) with 5 A output current
  • Load voltage of 24 V DC and 24-230 V AC
  • Can be used up to Category 4 (EN 954-1)/ SIL3 (IEC61508)/ PLE (ISO13849)
  • 30 mm overall width
  • Failsafe operation at 24 V DC/5A and 24-230 V AC/5A

Accessories



Product

Manufacturer Material ID -
6ES7138-4FR00-0AA0
Net Weight -
0.11kg

Additional Product Information

Commodity Code -
85389091
Country of Origin -
DE
Minimum Order Quantity -
1
UNSPSC -
32151705

Technical Specification

-
Siemens
Input current at signal 1 -
- Milliampere
Time delay at signal exchange -
- Millisecond
Type of voltage (input voltage) -
UN
Supply voltage AC 50 Hz -
- Volt
Supply voltage AC 60 Hz -
- Volt
Permitted voltage at input -
- Volt
Degree of protection (IP) -
IP20
Category according to EN 954-1 -
4
Number of interfaces PROFINET -
0
Front build in possible -
Performance level acc. EN ISO 13849-1 -
Level e
Type of electric connection -
Screw-/spring clamp connection
Explosion safety category for gas -
ATEX gas-ex-protection, Cat. 3G
Explosion safety category for dust -
None
Performance level acc. to EN ISO 13849-1 -
Level e
SIL according to IEC 61508 -
3
Degree of protection (IP rating) -
IP20
Depth -
52 Millimetre
Digital outputs configurable -
Fieldbus connection over separate bus coupler possible -
Height -
81 Millimetre
Number of digital inputs -
0
Number of digital outputs -
1
Number of HW-interfaces industrial Ethernet -
0
Number of HW-interfaces other -
0
Number of HW-interfaces parallel -
0
Number of HW-interfaces PROFINET -
0
Number of HW-interfaces RS-232 -
0
Number of HW-interfaces RS-422 -
0
Number of HW-interfaces RS-485 -
0
Number of HW-interfaces serial TTY -
0
Number of HW-interfaces USB -
0
Number of HW-interfaces Wireless -
0
Output current -
5 Ampere
Permitted voltage at output -
2 Volt
Rail mounting possible -
Suitable for safety functions -
Supply voltage DC -
20.4 Volt
Supporting protocol for PROFIsafe -
System accessory -
Type of digital output -
Relay
Type of output voltage -
AC/DC
Voltage type of supply voltage -
DC
Width -
30 Millimetre
