540334

KVI-CP-3-GS-GD-8 Connecting cable

Manufacturer's No: KVI-CP-3-GS-GD-8     Manufacturer: Festo
KVI-CP-3-GS-GD-8 Connecting cable

Availability Back Order

£21.55
  • Product: KVI-CP-3-GS-GD-8 Connecting Cable
  • Cable Type: Straight, 5-pin/-wire
  • Cable Material: TPE-U(PUR)
  • Cable Length: 8m
  • Plug Type: M9, Straight, 5-pin/-wire, IP65/IP67
  • Additional Function: Contact 3 of socket 1mm leading
  • Frequency of Connection: 500
  • Weight: 397g
  • Electrical Connection 1: Field device side, Round design, Socket type, M9x0.5 connector system, 5 connections/cores
  • Electrical Connection 2: Controller side, Round design, Plugs type, M9x0.5 connector system, 5 connections/cores

Read more

  • Operational Voltage Range DC: 0V to 30V
  • Current Rating at 40°C: 1.6A
  • Permissible Current Load at 40°C: 2.3A for 0.34 mm², 3.6A for 0.49 mm²
  • Immunity to Surge: 1.5KV
  • Shielding: Yes
  • Cable Diameter: 5.5mm
  • Cable Structure: 2 x 0.25 mm² + 2 x 0.34 mm² + 0.49 mm²
  • Bending Radius: 75mm for moving cable
  • Degree of Protection: IP65, IP67
  • Ambient Temperature: -20°C to 80°C, -5°C to 80°C with moving cable
  • CE Mark: In accordance with EU RoHS Directive
  • UKCA Marking: To UK RoHS instructions
  • LABS (PWIS) Conformity: VDMA24364-B2-L
  • Materials: RoHS-compliant, TPE-U(PUR) cable sheath, PA, PBT, TPE-U(PUR) housing, Nickel-plated brass screw-type lock, Gold-plated bronze and brass electrical contacts, TPE-U(PUR) insulating sheath


Product

Manufacturer Material ID -
KVI-CP-3-GS-GD-8
Net Weight -
0.02kg

Additional Product Information

Commodity Code -
85369010
Country of Origin -
DE
UNSPSC -
39121529

Technical Specification

Accessory -
Type of accessory/spare part -
Other
