3SE51150CA001AD0

Basic switch for position switch 3SE51 Metal enclosure 40 mm according to EN 50041 with connector 6+

Manufacturer's No: 3SE5115-0CA00-1AD0     Manufacturer: Siemens
Basic switch for position switch 3SE51 Metal enclosure 40 mm according to EN 50041 with connector 6+

View 3D

Availability Back Order

£88.44
  • Basic position switch 3SE51
  • Metal enclosure with dimensions 40 mm according to DIN EN 50041
  • Plug 6+PE (3SY3131) according to EN 43651
  • 1 normally open (NO) / 1 normally closed (NC) quick action contacts
  • Pin assignment: Pin1=21, Pin2=22, Pin3=13, Pin4=14
  • Pins 5 and 6 not connected
  • Protective earth (PE) connected with quick change device 3SY3110 + 3SY3027

Selectable mandatory product

Accessories

Component part

Product video
Product video


Product

Manufacturer Material ID -
3SE5115-0CA00-1AD0
Net Weight -
0.46kg

Additional Product Information

Commodity Code -
85365080
Country of Origin -
DE
Export Control Regulations -
N / N
Minimum Order Quantity -
1
UNSPSC -
39122216

Technical Specification

Rated operation current Ie at AC-15, 230 V -
- Ampere
Rated operation current Ie at DC-13, 230 V -
- Ampere
Diameter sensor -
- Millimetre
Material housing -
Metal
Degree of protection (IP) -
IP65
Type of interface -
None
Type of control element -
None
Alignment of the control element -
Roller cam straight
Ambient temperature during operating -
-25 Degrees celsius
Coating housing -
Lacquered
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP65
Degree of protection (NEMA) -
12
Explosion safety category for dust -
None
Explosion safety category for gas -
None
Forced opening -
Height of sensor -
50.8 Millimetre
Housing material -
Metal
Interface type -
None
Length of sensor -
141.5 Millimetre
Number of contacts as change-over contact -
0
Number of contacts as normally closed contact -
1
Number of contacts as normally open contact -
1
Number of safety auxiliary contacts -
1
Rated operation current Ie at AC-15, 125 V -
6 Ampere
Rated operation current Ie at AC-15, 24 V -
6 Ampere
Rated operation current Ie at DC-13, 125 V -
0.55 Ampere
Rated operation current Ie at DC-13, 24 V -
3 Ampere
Suitable for safety functions -
Switching function -
Quick-break switch
Type of electric connection -
Plug-in connection others
Type of interface for safety communication -
None
Width sensor -
40 Millimetre

Availability Back Order

£88.44
