3SE51141CD021AF5

Position switch with roller plunger metal enclosure 40 mm, EN50041, 1 NO/1 NC

Manufacturer's No: 3SE5114-1CD02-1AF5     Manufacturer: Siemens
Position switch with roller plunger metal enclosure 40 mm, EN50041, 1 NO/1 NC

View 3D

Availability Back Order

£81.07
  • Position switch with Roller plunger
  • Metal enclosure 40 mm according to EN 50041
  • 1 NO/1 NC quick action contact
  • M12 connector, 5-pole
  • Fixed installation
  • 2 LEDs (yellow/green)
  • 24 V DC, 4 A
  • Pin assignment:
    • Pin1: 21+13 Jumper + LED green
    • Pin2: 22
    • Pin3: ground LED
    • Pin4: 14 + LED yellow
    • Pin5: PE
  • Pin1: 21+13 Jumper + LED green
  • Pin2: 22

Read more

  • Pin3: ground LED
  • Pin4: 14 + LED yellow
  • Pin5: PE

Accessories

Component part



Product

Manufacturer Material ID -
3SE5114-1CD02-1AF5
Net Weight -
0.37kg

Additional Product Information

Commodity Code -
85365080
Country of Origin -
DE
RoHs Compliance -
Yes
UNSPSC -
39122213

Technical Specification

Rated operation current Ie at AC-15, 230 V -
- Ampere
Rated operation current Ie at DC-13, 230 V -
- Ampere
Rated operation current Ie at AC-15, 125 V -
- Ampere
Rated operation current Ie at AC-15, 24 V -
- Ampere
Rated operation current Ie at DC-13, 125 V -
- Ampere
Diameter sensor -
- Millimetre
Switching function -
Quick-break switch
Material housing -
Metal
Suitable for safety functions -
Coating housing -
Lacquered
With status indication -
Type of interface for safety communication -
None
Type of electric connection -
Plug-in connection M12
Explosion safety category for gas -
None
Explosion safety category for dust -
None
Construction type housing -
Cuboid
Degree of protection (IP) -
IP66/IP67
Forced opening -
Number of safety auxiliary contacts -
1
Type of control element -
Roller cam
Type of interface -
None
Rated operation current Ie at DC-13, 24 V -
3 Ampere
Width sensor -
40 Millimetre
Height of sensor -
37.3 Millimetre
Length of sensor -
130.5 Millimetre
Ambient temperature during operating -
-25 Degrees celsius
Number of contacts as normally closed contact -
1
Number of contacts as normally open contact -
1
Number of contacts as change-over contact -
0
Alignment of the control element -
Roller cam straight
Degree of protection (NEMA) -
12

Availability Back Order

£81.07
