3SE51141CA001AF5

Basic switch for position switch 3SE51 Metal enclosure 40 mm according to EN 50041 1 NO/1 NC quick a

Manufacturer's No: 3SE5114-1CA00-1AF5     Manufacturer: Siemens
Basic switch for position switch 3SE51 Metal enclosure 40 mm according to EN 50041 1 NO/1 NC quick a

View 3D

Availability Back Order

£66.33
  • Basic switch for position switch 3SE51
  • Metal enclosure with dimensions of 40 mm according to EN 50041
  • 1 Normally Open (NO) / 1 Normally Closed (NC) quick action contact
  • Equipped with an M12 connector (5-pole)
  • Features 2 LEDs (yellow and green)
  • Operating voltage: 24 V DC
  • Maximum current: 4 A
  • Pin assignment:
    • Pin 1: 21+13 Jumper + LED green
    • Pin 2: 22
    • Pin 3: ground LED
    • Pin 4: 14 + LED yellow
    • Pin 5: PE
  • Pin 1: 21+13 Jumper + LED green
  • Pin 2: 22

Read more

  • Pin 3: ground LED
  • Pin 4: 14 + LED yellow
  • Pin 5: PE

Selectable mandatory product

Accessories

Component part



Product

Manufacturer Material ID -
3SE5114-1CA00-1AF5
Net Weight -
0.32kg

Additional Product Information

Commodity Code -
85365080
Country of Origin -
DE
Export Control Regulations -
N / N
Minimum Order Quantity -
1
UNSPSC -
39122216

Technical Specification

Rated operation current Ie at AC-15, 230 V -
- Ampere
Rated operation current Ie at DC-13, 230 V -
- Ampere
Rated operation current Ie at AC-15, 125 V -
- Ampere
Rated operation current Ie at AC-15, 24 V -
- Ampere
Rated operation current Ie at DC-13, 125 V -
- Ampere
Diameter sensor -
- Millimetre
Material housing -
Metal
Type of electric connection -
Plug-in connection M12
Degree of protection (IP) -
IP66/IP67
Type of interface -
None
Switching function -
Quick-break switch
Housing material -
Metal
Suitable for safety functions -
Coating housing -
Lacquered
With status indication -
Type of interface for safety communication -
None
Explosion safety category for gas -
None
Explosion safety category for dust -
None
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP66/IP67
Forced opening -
Number of safety auxiliary contacts -
1
Type of control element -
None
Interface type -
None
Rated operation current Ie at DC-13, 24 V -
3 Ampere
Width sensor -
40 Millimetre
Height of sensor -
37.3 Millimetre
Length of sensor -
130.5 Millimetre
Ambient temperature during operating -
-25 Degrees celsius
Number of contacts as normally closed contact -
1
Number of contacts as normally open contact -
1
Number of contacts as change-over contact -
0
Alignment of the control element -
Roller cam straight
Degree of protection (NEMA) -
12
