3SE51140QV101AE3

Safety position switch, separate actuator, metal encl. 40 mm, 5-pole

Manufacturer's No: 3SE5114-0QV10-1AE3     Manufacturer: Siemens
Safety position switch, separate actuator, metal encl. 40 mm, 5-pole

View 3D

Availability Back Order

£91.52
  • Safety position switch with separate actuator
  • Metal enclosure 40 mm
  • M12 connector, plastic 5-pole
  • Max. 125 V, 4 A
  • 5 directions of approach
  • Slow-action contacts: 2 NC connected
  • Suitable for connection to all SIMATIC ET200* compact block I/O modules
  • Matching separate Actuator 3SE5000-0AV../W.. must be ordered separately

Selectable mandatory product

Accessories

Component part

Product video
Product video


Product

Manufacturer Material ID -
3SE5114-0QV10-1AE3
Net Weight -
0.47kg

Additional Product Information

Commodity Code -
85365080
Country of Origin -
DE
RoHs Compliance -
Yes
UNSPSC -
39122213

Technical Specification

Rated operation current Ie at AC-15, 230 V -
- Ampere
Rated operation current Ie at DC-13, 230 V -
- Ampere
Diameter sensor -
- Millimetre
Material housing -
Metal
Type of electric connection -
Plug-in connection M12
Degree of protection (IP) -
IP66/IP67
Type of interface -
None
Alignment of the control element -
Roller cam straight
Ambient temperature during operating -
-25 Degrees celsius
Coating housing -
Lacquered
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP66/IP67
Degree of protection (NEMA) -
12
Explosion safety category for dust -
None
Explosion safety category for gas -
None
Forced opening -
Height of sensor -
37.3 Millimetre
Housing material -
Metal
Interface type -
None
Length of sensor -
124 Millimetre
Number of contacts as change-over contact -
0
Number of contacts as normally closed contact -
2
Number of contacts as normally open contact -
1
Number of safety auxiliary contacts -
2
Rated operation current Ie at AC-15, 125 V -
4 Ampere
Rated operation current Ie at AC-15, 24 V -
4 Ampere
Rated operation current Ie at DC-13, 125 V -
0.55 Ampere
Rated operation current Ie at DC-13, 24 V -
3 Ampere
Suitable for safety functions -
Switching function -
Slow-action switch
Type of control element -
None
Type of interface for safety communication -
None
Width sensor -
40 Millimetre

Availability Back Order

£91.52
