286-891

Component module with fuse, for (5 x 20) mm microfuse, Nominal voltage: 230 VAC/DC, gray

Manufacturer's No: 286-891     Manufacturer: WAGO
Component module with fuse, for (5 x 20) mm microfuse, Nominal voltage: 230 VAC/DC, gray

Availability Back Order

£28.56
  • Component module for (5 x 20) mm microfuse
  • Nominal voltage: 230 VAC/DC
  • Color: Gray

Accessories



Product

Manufacturer Material ID -
286-891
Net Weight -
0.50kg

Additional Product Information

Commodity Code -
85364900
Country of Origin -
DE
Minimum Order Quantity -
1
UNSPSC -
39121529

Technical Specification

Rated current In -
- Ampere
Length -
50 Millimetre
Operation temperature -
105 Degrees celsius
Width/grid dimension -
10 Millimetre
Height at lowest possible mounting height -
70.2 Millimetre
Connection position -
Above
Colour -
Grey
Connectable conductor cross section fine-strand with cable end sleeve -
0.25 Square millimetre
Connectable conductor cross section fine-strand without cable end sleeve -
0.08 Square millimetre
Connectable conductor cross section multi-wired -
0.08 Square millimetre
Connectable conductor cross section solid-core -
0.08 Square millimetre
Depth -
52 Millimetre
Inflammability class of insulation material acc. with UL94 -
V0
Material insulation body -
Thermoplastic
Mounting method -
Other
Number of levels -
1
Operating temperature -
-25 Degrees celsius
Rated voltage -
250 Volt
Supply voltage for defect-indication -
230 Volt
Type of electrical connection 1 -
Spring clamp connection
Type of electrical connection 2 -
Spring clamp connection
Type of fuse holder -
Pluggable
Type of fuse insert -
G-fuse 5x20 mm
Type of indication element for defect indication -
Other
Voltage type for defect indication -
AC/DC
Width -
10 Millimetre

Availability Back Order

£28.56
