2004-554

TOPJOBS Connector Strip, For Jumper Contact Slot 4-Pole Gray

Manufacturer's No: 2004-554     Manufacturer: WAGO
TOPJOBS Connector Strip, For Jumper Contact Slot 4-Pole Gray

Availability Back Order

Once added to the cart, you can split this pack for a charge of £16.00

£4.905
List Price £6.54
  • Modular TOPJOB®S connector
  • 4-pole
  • For jumper contact slot
  • 4.00 mm² wire size
  • Color: Gray

Accessories

Ferrule, Sleeve For 0.75 mm / Awg 20 Insulated Gray

Once added to the cart, you can split this pack for a charge of £16.00

Product Code - 216-242
Price £0.09
Back Order

Ferrule, Sleeve For 0.75 mm / Awg 20 Insulated Gray

Once added to the cart, you can split this pack for a charge of £16.00

Product Code - 216-262
Price £0.09
Back Order

Ferrule, Sleeve For 1 mm / Awg 18 Insulated Red

Once added to the cart, you can split this pack for a charge of £16.00

Product Code - 216-263
Price £0.09
Back Order

Ferrule, Sleeve For 1.5 mm / Awg 16 Insulated Black

Once added to the cart, you can split this pack for a charge of £16.00

Product Code - 216-244
Price £0.09
Back Order

Ferrule, Sleeve For 1.5 mm / Awg 16 Insulated Black

Once added to the cart, you can split this pack for a charge of £16.00

Product Code - 216-264
Price £0.09
Back Order

Ferrule, Sleeve For 2.5 mm / Awg 14 Insulated Blue

Once added to the cart, you can split this pack for a charge of £16.00

Product Code - 216-246
Price £0.09
Back Order

Ferrule, Sleeve For 2.5 mm / Awg 14 Insulated Blue

Once added to the cart, you can split this pack for a charge of £16.00

Product Code - 216-266
Price £0.09
Back Order

Ferrule, Sleeve For 2.5 mm / Awg 14 Insulated Blue

Once added to the cart, you can split this pack for a charge of £16.00

Product Code - 216-286
Price £0.14
Back Order

Ferrule; Sleeve for 4 mm / AWG 12; insulated; electro-tin plated; electrolytic copper; gastight crimped; acc. to DIN 46228, Part 4/09.90

Once added to the cart, you can split this pack for a charge of £16.00

Product Code - 216-267
Price £0.09
Back Order

Ferrule, Sleeve For 4 mm / Awg 12 Insulated Gray

Once added to the cart, you can split this pack for a charge of £16.00

Product Code - 216-287
Price £0.14
Back Order

Insulation Stop, 0.25 - 0.5 mm 5 Pieces/Strip Light Gray

Once added to the cart, you can split this pack for a charge of £16.00

Product Code - 2004-171
Price £0.1425
List Price £0.19
Back Order


Product

Manufacturer Material ID -
2004-554
Net Weight -
0.02kg

Additional Product Information

Commodity Code -
85369010
Country of Origin -
DE
Minimum Order Quantity -
25
UNSPSC -
39121402

Technical Specification

Width/grid dimension -
6.2 Millimetre
Model -
Pin insert
Rated voltage -
500 Volt
Number of poles -
4
Type of electric connection -
Spring clamp connection
Tackable -
Total number of poles (without ground contact) -
4
Connectable conductor cross section solid-core -
1 Square millimetre
Connectable conductor cross section fine-strand with cable end sleeve -
0.75 Square millimetre
Connectable conductor cross section fine-strand without cable end sleeve -
0.5 Square millimetre
Connectable conductor cross section multi-wired -
0.5 Square millimetre
Connectable conductor cross section -
0.5 Square millimetre
Rated current In -
32 Ampere
