2000-558

Modular TOPJOBS connector, modular, for jumper contact slot, 8-pole, 1, 00 mm, gray

Manufacturer's No: 2000-558     Manufacturer: WAGO
Modular TOPJOBS connector, modular, for jumper contact slot, 8-pole, 1, 00 mm, gray

Availability Back Order

POA
  • Modular TOPJOB®S connector
  • 8-pole
  • Designed for jumper contact slot
  • Wire size: 1.00 mm²
  • Color: Gray

Accessories

Ferrule, Sleeve For 0.5 mm / Awg 22 Insulated White

Once added to the cart, you can split this pack for a charge of £16.00

Product Code - 216-241
Price £0.09
Back Order

Ferrule, Sleeve For 0.75 mm / Awg 20 Insulated Gray

Once added to the cart, you can split this pack for a charge of £16.00

Product Code - 216-242
Price £0.09
Back Order

Strain Relief Plate, Can Be Snapped On Tap-Off Modules 25 mm Wide Gray

Once added to the cart, you can split this pack for a charge of £16.00

Product Code - 734-329
Price £0.38
Back Order


Product

Manufacturer Material ID -
2000-558
Net Weight -
0.19kg

Additional Product Information

Commodity Code -
85365005
Country of Origin -
DE
Minimum Order Quantity -
10
UNSPSC -
39121410

Technical Specification

Width/grid dimension -
3.5 Millimetre
Model -
Pin insert
Rated voltage -
500 Volt
Number of poles -
8
Type of electric connection -
Spring clamp connection
Tackable -
Total number of poles (without ground contact) -
8
Connectable conductor cross section solid-core -
0.14 Square millimetre
Connectable conductor cross section fine-strand with cable end sleeve -
0.5 Square millimetre
Connectable conductor cross section fine-strand without cable end sleeve -
0.14 Square millimetre
Connectable conductor cross section multi-wired -
0.14 Square millimetre
Connectable conductor cross section -
0.14 Square millimetre
Rated current In -
13.5 Ampere

Availability Back Order

POA
